Material: NdFeB
Part No.:
Shape: Disc
Materials: NdFeB
Grade: N35SH
Dimensions: 6mm dia. x 2.5mm thick
Tolerance: ±0.1mm x ±0.05mm
Magnetization Direction: Through Thickness
Coating: Nickel Coated Magnets
In stock: 500pcs
Material: NdFeB
Part No.: SMBN0446
Shape: Block
Materials: NdFeB
Grade: N52
Dimensions: 1/2'' x 1/2'' x 1/8'' thick
Tolerance: ±0.004”
Magnetization Direction: Through Thickness
Coating: Nickel Coated Magnets
In stock: 500pcs
Material: NdFeB
Part No.:
Shape: Disc
Materials: NdFeB
Grade: N40SH
Dimensions: 0.32" diameter x 0.08" thickness
Tolerance: ±0.004”
Magnetization Direction: Through Thickness (Axially)
Coating: Nickel Coated Magnets
In stock: 6000pcs
Material: NdFeB
Part No.:
Shape: Disc
Materials: NdFeB
Grade: N52
Dimensions: 1/16" diameter x 1/8" thick
Tolerance: ±0.004”
Magnetization Direction: Through Thickness (Axially)
Coating: Nickel Coated Magnets
In stock: 600pcs
Material: NdFeB
Part No.:
Shape: Arc
Materials: NdFeB
Grade: N52
Dimensions: 44.75mm O.R.x 40mm I.R. x 4mm T. x 11.50 Degrees
Tolerance: +/-0.05 mm
Magnetization Direction: Through Thickness
(Mark the North Pole With A Red Dot)
Coating: Nickel Coated Magnets
In stock: 700pcs
Material: NdFeB
Part No.:
Shape: Arc
Materials: NdFeB
Grade: N52
Dimensions: 18mm O.R.x 14mm I.R. x 3mm T. x 33.54 Degrees
Tolerance: +/-0.05 mm
Magnetization Direction: Through Thickness
(Mark the North Pole With A Red Dot)
Coating: Nickel Coated Magnets
In stock: 2400pcs
Material: NdFeB
Part No.:
Shape: Disc
Materials: NdFeB
Grade: N42
Dimensions: 1 1/8" Dia x 1/2" Thick
Tolerance: ±0.004”
Magnetization Direction: Through Thickness (Axially)
Coating: Nickel Coated Magnets
In stock: 3800pcs
Neodymium Disc/Cylinder Magnets in Stock | ||||||
Grade | Size(mm) | O.D.(mm) | I.D.(mm) | High (mm) | Coating | In stock (pcs) |
N42 | 19.05*4.06*3.18-D7.37 | 19.05 | 4.06 | 3.18 | Epoxy | 110 |
N42 | 19.05*4.57 | 19.05 | 4.57 | Epoxy | 322 | |
N42 | 19.05*4.75 | 19.05 | 4.75 | Epoxy | 680 | |
N42 | 20.64*2.38 | 20.64 | 2.38 | NI | 251 | |
N42 | 20.65*8.3 | 20.65 | 8.3 | ZN | 1767 | |
N42 | 24.5*2 | 24.5 | 2 | ZN | 346 | |
N42 | 24.5*3 | 24.5 | 3 | 3+ZN | 418 | |
N42 | 24.5*3.5 | 24.5 | 3.5 | ZN | 101 | |
N42 | 24.5*4 | 24.5 | 4 | White 3+ZN | 560 | |
N52 | 3*1.5 | 3 | 1.5 | NI | 200 | |
N52 | 3*2 | 3 | 2 | NI | 818 | |
N52 | 3*2 | 3 | 2 | Black NI | 346 | |
N52 | 3.5*2 | 3.5 | 2 | NI | 1460 | |
N52 | 4.75*3.18 | 4.75 | 3.18 | NI | 1330 | |
N52 | 4.76*1.59 | 4.76 | 1.59 | NI | 270 | |
N52 | 4.76*2.43 | 4.76 | 2.43 | NI | 185 | |
N52 | 4.76*3.17 | 4.76 | 3.17 | NI | 5450 | |
N52 | 9*3.5 | 9 | 3.5 | NI | 2610 | |
N52 | 9.53*0.79 | 9.53 | 0.79 | NI | 200 | |
N52 | 9.53*1.52 | 9.53 | 1.52 | NI | 1220 | |
N52 | 9.53*1.57 | 9.53 | 1.57 | NI | 405 | |
N52 | 9.53*1.59 | 9.53 | 1.59 | NI | 186 | |
N52 | 12*2 | 12 | 2 | NI | 6392 |
Neodymium Arc Magnet in Stock | |||||||
Grade | Size(mm) | R (mm) | r (mm) | Angel | Height(mm) | Coating | In stock (pcs) |
N30SH | R33.27*R30.07*45°*24.84 | 33.27 | 30.07 | 45 | 24.84 | NI | 277 |
N30SH | R33.5*R30.5*11.35*28 | 33.5 | 30.5 | 11.35 | 28 | NI | 173 |
N35 | R11.9*R8*12.81*25 | 11.9 | 8 | 12.81 | 25 | NI | 580 |
N35 | R11.9*R8*12.81*33 | 11.9 | 8 | 12.81 | 33 | NI | 424 |
N35EH | R13.25*R11.45*17*4 | 13.25 | 11.45 | 17 | 4 | Epoxy | 212 |
N35EH | R13.25*R11.45*4*17 | 13.25 | 11.45 | 4 | 17 | Epoxy | 134 |
N35H | R15*R15*90°*40 | 15 | 15 | 90 | 40 | ZN | 485 |
N35H | R15*R15*90°*60 | 15 | 15 | 90 | 60 | ZN | 5841 |
N35H | R15.5*R22.8*16.5*17.5 | 15.5 | 22.8 | 16.5 | 17.5 | ZN | 1067 |
N35H | R15.5*R22.8*16.5*22*3 | 15.5 | 22.8 | 16.5 | 3 | ZN | 13992 |
N35SH | R22*22*14.4*30 | 22 | 22 | 14.4 | 30 | 3+ZN | 57418 |
N35SH | R27.5*R23.5*9.48*31 | 27.5 | 23.5 | 9.48 | 31 | NI | 1630 |
Neodymium Block Magnets in Stock | |||||||
Part No. | Grade | Size (mm) | Length(mm) | Width (mm) | Height(mm) | Coating | In stock (pcs) |
N28R | 7*7*3 | 7 | 7 | 3 | NI | 1033 | |
N28R | 25*6*2 | 25 | 6 | 2 | NI | 890 | |
N28R | 30*10*2 | 30 | 10 | 2 | NI | 482 | |
N33SB0100302-201NN | N33SHT | 10*2.9*2 | 10 | 2.9 | 2 | NI | 5400 |
N35-B0420702-001ZN | N35 | 42*7*2 | 42 | 7 | 2 | 3+ZN | 1358 |
N35 | 50*10*0.8 | 50 | 10 | 0.8 | ZN | 1275 | |
N35EH | 1.6*1.6*5 | 1.6 | 1.6 | 5 | NI | 2072 | |
N35H | 36.7*8*4 | 36.7 | 8 | 4 | Epoxy | 1464 | |
N35SB0060603-801NN | N35SH | 6.35*6.35*3.3-R12.95 | 6.35 | 6.35 | 3.3 | NI | 2888 |
N35SH | E6.5*2.8*3 | 6.5 | 2.8 | 3 | NI | 3188 | |
N40 | 15*5*1 | 15 | 5 | 1 | 3+ZN | 3645 | |
N40 | 15*5*1.5 | 15 | 5 | 1.5 | ZN | 5235 | |
N40-B0370402-001ZN | N40 | 37*4*2 | 37 | 4 | 2 | 3+ZN | 15275 |
N48H | 6*5*2 | 6 | 5 | 2 | NI | 1060 | |
N48H | E6.15*5.35*5.59-R2.68 | 6.15 | 5.35 | 5.59 | NI | 2043 |
AlNiCo Magnets & SmCo Magnets in Stock | ||||||
Part No. | Grade | Size (mm) | O.D.(mm) | I.D.(mm) | Height(mm) | In stock (pcs) |
SM2CO17 | F13.4*13.4*3.5 | 13.4 | 13.4 | 3.5 | 110 | |
S20ND0100003-001 | YXG20 | 10*3 | 10 | 3 | 1894 | |
S26ND0040002-001 | YXG26 | 4*2 | 4 | 2 | 305 | |
S28NA065601670-301 | YXG28 | R65*R60*16.3*70 | 65 | 60 | 16.3 | 440 |
YXG30H | R27.5*R22*25.5°*45 | 27.5 | 22 | 25.5 | 725 | |
YXG30H | R38.5*R32.5*25.5°*45-3*3.2 | 38.5 | 32.5 | 25.5 | 723 |
