Product ID: SMAN2907
Material: NdFeB
Shape: Arc
Dimension: 118.00mm (4.646in) outside radius x 105.50mm (4.154in) inside radius x 25.00mm (0.984in) thick x 10.0 degree arc
Grade: N42
Coating: Nickel Coated Magnets
Magnetization direction: Magnetized through radius
Max Operating Temp(C/F): 80/176
South on the outside face
SMAN2907 Custom NdFeB Arc Magnet | Stanford Magnets
SMAN2907 Custom NdFeB Arc Magnet
