SMBN0378 Neodymium Block Magnet

Product ID: SMBN0378
Material: NdFeB
Shape: Block
Dimension: 1/16” x 1/16” x 1/16” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight (Oz.): 0.0021
Grade: N42
Coating: Nickel Coated Magnets
Pull Force (Lbs): 0.14
Surface Field (Gauss): 5754
Magnetization Direction: Through Thickness
Magnetic Face: 1/16″ x 1/16″
Max Operating Temp (C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


SMBN0378 Neodymium Block Introduction

The SMBN0378 Neodymium Block Magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1/16″ × 1/16″ × 1/16″ thick, magnetized through thickness, with tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.0001325 lbs. It can pull up to 0.14 lbs steel. And its surface field is up to 5754 gauss.

SMBN0378 Neodymium Block Magnet Safety Tips

The SMBN0378 Neodymium Block Magnet is so small that children could swallow it easily. If several magnets are swallowed, they could get stuck in the intestine and cause perilous complications. Magnets are not toys, so make sure that children do not play with them. The smbn0378 neodymium block magnet could also be used as like push pins and fridge magnets. Keep track of all rare earth magnets in a home, not just those located in toys.
