SMBN0400 Neodymium Countersunk Magnet

Product ID: SMBN0400
Material: NdFeB
Shape: Countersunk
Dimension: 1/4” x 1/4” x 1/4” (- 1/16” hole)
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 0.068
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 4.05
Surface Field(Gauss): 4045
Magnetization Direction: Through Thickness
Magnetic Face: 1/4″ x 1/4″
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


Description

The SMBN0400 countersunk neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1/4″ × 1/4″ × 1/4″ (- 1/16″ hole), magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.00425 lbs. It can pull up to 4.05 lbs steel. And the surface field is up to 4045 gausses.
