Name: SMBN0421 Neodymium Countersunk Magnet
SKU: SMBN0421

SMBN0421 Neodymium Countersunk Magnet

The SMBN0421 BLOCK neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 3/8″ × 3/8″ × 3/8″ (- 3/32″ hole), magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.012875 lbs. It can pull up to 9.44 lbs steel. And the surface field is up to 5294 gauss.

INQUIRY Can't Find The Size

Follow Us On

Description

Description

Product ID: SMBN0421
Material: NdFeB
Shape: Countersunk
Dimension: 3/8” x 3/8” x 3/8” (- 3/32” hole)
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 0.21
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 9.44
Surface Field(Gauss): 5294
Magnetization direction: Through Thickness
Magnetic Face: 3/8″ x 3/8″
Max Operating Temp(C/F): 80/176
