SMBN0490 Neodymium Block Magnet

Product ID: SMBN0490
Material: NdFeB
Shape: Block
Dimension: 3/4” x 3/4” x 1/2” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 1.22
Grade: N42
Coating: Rubber Coated Magnets
Pull Force(Lbs): 34.46
Surface Field(Gauss): 5053
Magnetization Direction: Through Thickness
Magnetic Face: 3/4″ x 3/4″
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


Description

The SMBN0490 block neodymium magnet is made from high performance N42 NdFeB, with Black Rubber coating. The dimension of this item is 3/4″ × 3/4″ × 1/2″ thick, magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.07625 lbs. It can pull up to 34.46 lbs steel. And the surface field is up to 5053 gausses.
