SMBN0528 Neodymium BLOCK Magnet - Stanford Magnets

SMBN0528 Neodymium BLOCK Magnet

The SMBN0528 BLOCK neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1″ × 3/4″ × 3/4″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.1525 lbs. It can pull up to 53.06 lbs steel. And the surface field is up to 5547 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMBN0528
Material: NdFeB
Shape: Block
Dimension: 1” x 3/4” x 3/4” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 2.44
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 53.06
Surface Field(Gauss): 5547
Magnetization direction: Through Thickness
Magnetic Face: 1″ x 3/4″
Max Operating Temp(C/F): 80/176
