SMBN0562 Neodymium BLOCK Magnet

The SMBN0562 BLOCK neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1 1/2″ × 3/4″ × 1/2″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.1525 lbs. It can pull up to 58.46 lbs steel. And the surface field is up to 4404 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMBN0562
Material: NdFeB
Shape: Block
Dimension: 1 1/2” x 3/4” x 1/2” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 2.44
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 58.46
Surface Field(Gauss): 4404
Magnetization direction: Through Thickness
Magnetic Face: 1 1/2″ x 3/4″
Max Operating Temp(C/F): 80/176
