SMBN0568 Neodymium Block Magnet | Stanford Magnets

SMBN0568 Neodymium Block Magnet

Product ID: SMBN0568
Material: NdFeB
Shape: Block
Dimension: 1 1/2” x 1 1/2” x 1/8” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 1.22
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 23.29
Surface Field(Gauss): 979
Magnetization Direction: Through Thickness
Magnetic Face: 1 1/2″ x 1 1/2″
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


Description

The SMBN0568 block neodymium magnet is made from high-performance N42 NdFeB, with Nickel coating. The dimension of this item is 1 1/2″ × 1 1/2″ × 1/8″ thick, magnetized Through Thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.07625 lbs. It can pull up to 23.29 lbs steel. And the surface field is up to 979 gauss.
