SMBN0572 Neodymium BLOCK Magnet | Stanford Magnets

SMBN0572 Neodymium BLOCK Magnet

The SMBN0572 BLOCK neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1 1/2″ × 1 1/2″ × 1″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.61 lbs. It can pull up to 154.5 lbs steel. And the surface field is up to 5053 gauss.SMBN0572 Neodymium BLOCK Magnet Safety TipsThe smbn0572 neodymium block magnet has a very strong attractive force. Unsafe handling could cause jamming of fingers or skin in between magnets. This may lead to contusions and bruises.You should always wear heavy protective gloves and eye protection when handling the smbn0572 neodymium block magnet.Store the smbn0572 neodymium block magnet at least one meter away from your body.Separate this item with a piece of cardboard.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMBN0572
Material: NdFeB
Shape: Block
Dimension: 1 1/2” x 1 1/2” x 1” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 9.76
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 154.5
Surface Field(Gauss): 5053
Magnetization direction: Through Thickness
Magnetic Face: 1 1/2″ x 1 1/2″
Max Operating Temp(C/F): 80/176 SMBN0572 Neodymium BLOCK Magnet Safety Tips
The smbn0572 neodymium block magnet has a very strong attractive force. Unsafe handling could cause jamming of fingers or skin in between magnets. This may lead to contusions and bruises.

You should always wear heavy protective gloves and eye protection when handling the smbn0572 neodymium block magnet.
Store the smbn0572 neodymium block magnet at least one meter away from your body.
Separate this item with a piece of cardboard.
