SMBN0624 Neodymium Block Magnet

Product ID: SMBN0624
Material: NdFeB
Shape: Block
Dimension: 3” x 2” x 1” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 26
Grade: N52
Coating: Nickel Coated Magnets
Pull Force(Lbs): 439.1
Surface Field(Gauss): 4437
Magnetization Direction: Through Thickness
Magnetic Face: 3″ x 2″
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


SMBN0624 Neodymium Block Magnet Introduction

The SMBN0624 BLOCK neodymium magnet is made from high performance N52 NdFeB, with Nickel coating. The dimension of this item is 3″ × 2″ × 1″ thick, magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 1.625 lbs. It can pull up to 439.1 lbs steel. And the surface field is up to 4437 gausses.

SMBN0624 Neodymium Block Magnet Safety Tip

The smbn0624 neodymium block magnet has a very strong attractive force. Unsafe handling could cause jamming of fingers or skin in between magnets. This may lead to contusions and bruises.You should always wear heavy protective gloves and eye protection when handling the smbn0624 neodymium block magnet.Store the smbn0624 neodymium block magnet at least one meter away from your body.Separate this item with a piece of cardboard.
