SMCN0267 Neodymium CYLINDER Magnet

The SMCN0267 CYLINDER neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1/10″ dia. × 1/2″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.0010625 lbs. It can pull up to 0.6 lbs steel. And the surface field is up to 6567 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMCN0267
Material: NdFeB
Shape: Cylinder
Dimension: 1/10” dia. x 1/2” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 0.017
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 0.6
Surface Field(Gauss): 6567
Magnetization direction: Through Thickness
Magnetic Face: 1/10″ dia.
Max Operating Temp(C/F): 80/176
