SMCN0347 Neodymium Cylinder Magnet | Stanford Magnets

SMCN0347 Neodymium Cylinder Magnet

Product ID: SMCN0347
Material: NdFeB
Shape: Cylinder
Dimension: 1/2” dia. x 1” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 0.85
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 22.33
Surface Field(Gauss): 7157
Magnetization Direction: Diametrical
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


Description

The SMCN0347 cylinder neodymium magnet is made from high-performance N42 NdFeB, with Nickel coating. The dimension of this item is 1/2″ dia. × 1″ thick, magnetized diametrical, with the tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.0531875 lbs. It can pull up to 22.33 lbs steel. And the surface field is up to 7157 gausses.
