SMCN0759 Neodymium Countersunk Magnet

Product ID: SMCN0759
Material: NdFeB
Shape: Countersunk
Dimension: 1” x 1” x 3/16” thick w/ countersunk holes to accept #6 screws
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 0.75
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 22.95
Magnetization Direction: Through Thickness
Magnetic Face: 1″ x 1″
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


Description

The SMCN0759 countersunk neodymium magnet is made from high-performance N42 NdFeB, with Nickel coating. The dimension of this item is 1″ × 1″ × 3/16″ thick w/ countersunk holes to accept #6 screws, magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.046875 lbs. It can pull up to 22.95 lbs steel.
