SMDN0036 Neodymium DISC Magnet | Stanford Magnets

SMDN0036 Neodymium DISC Magnet

The SMDN0036 DISC neodymium magnet is made from high performance N52 NdFeB, with Black Nickel coating. The dimension of this item is 1/4″ dia. × 1/8″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.0016625 lbs. It can pull up to 2.85 lbs steel. And the surface field is up to 5233 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMDN0036
Material: NdFeB
Shape: Disc
Dimension: 1/4” dia. x 1/8” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 0.027
Grade: N52
Coating: Black Nickel Coated Magnets
Pull Force(Lbs): 2.85
Surface Field(Gauss): 5233
Magnetization direction: Through Thickness
Magnetic Face: 1/4″ dia.
Max Operating Temp(C/F): 80/176
