SMDN0194 Neodymium DISC Magnet | Stanford Magnets

SMDN0194 Neodymium DISC Magnet

The SMDN0194 DISC neodymium magnet is made from high performance N52 NdFeB, with Gold coating. The dimension of this item is 1″ dia. × 1/8″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.026625 lbs. It can pull up to 15.6 lbs steel. And the surface field is up to 1795 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMDN0194
Material: NdFeB
Shape: Disc
Dimension: 1” dia. x 1/8” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 0.43
Grade: N52
Coating: Gold Coated Magnets
Pull Force(Lbs): 15.6
Surface Field(Gauss): 1795
Magnetization direction: Through Thickness
Magnetic Face: 1″ dia.
Max Operating Temp(C/F): 80/176
