SMDN0208 Neodymium Disc Magnet | Stanford Magnets

SMDN0208 Neodymium Disc Magnet

Product ID: SMDN0208
Material: NdFeB
Shape: Disc
Dimension: 1” dia. x 3/4” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 2.55
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 55.3
Surface Field(Gauss): 5492
Magnetization Direction: Through Thickness
Magnetic Face: 1″ dia.
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


Description

The SMDN0208 disc neodymium magnet is made from high-performance N42 NdFeB, with Nickel coating. The dimension of this item is 1″ dia. × 3/4″ thick, magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.159375 lbs. It can pull up to 55.3 lbs steel. And the surface field is up to 5492 gausses.
