SMDN0219 Neodymium DISC Magnet | Stanford Magnets

SMDN0219 Neodymium DISC Magnet

The SMDN0219 DISC neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1 1/4″ dia. × 1 ” thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.3325 lbs. It can pull up to 91 lbs steel. And the surface field is up to 5597 gauss.

INQUIRY Can't Find The Size

Follow Us On


Product ID: SMDN0219
Material: NdFeB
Shape: Disc
Dimension: 1 1/4” dia. x 1 ” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 5.32
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 91
Surface Field(Gauss): 5597
Magnetization direction: Through Thickness
Magnetic Face: 1 1/4″ dia.
Max Operating Temp(C/F): 80/176
