SMDN0237 Neodymium Disc Magnets - Stanford Magnets

SMDN0237 Neodymium Disc Magnets

The SMDN0237 DISC neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 2 1/2″ dia. × 1/8″ thick, magnetized Through Thickness, with tolerance of ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.16625 lbs. It can pull up to 35.69 lbs steel. And the surface field is up to 657 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMDN0237
Material: NdFeB
Shape: Disc
Dimension: 2” dia. x 1” thick
Tolerances: ±0.004″ x ±0.004″
Weight(Oz.): 13.6
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 208
Surface Field(Gauss): 4667
Magnetization direction: Through Thickness
Magnetic Face: 2″ dia.
Max Operating Temp(C/F): 80/176
