SMMMS-D-X8 Standard Mounting Magnets

Dimensions:
Diameter = 1 1/2″ (1.50″)
Threaded Female Stud = #10-32 UNF 2B
Height = 3/8″ (0.375″)
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 2.64 oz. (74.77 g)
Pull Force: 95.78 lbs
Surface Field: N/A
Brmax: 13,200 Gauss
BHmax: 42 MGOe

The SMMMS-D-X8 is a flat mounting magnet with a female threaded shaft permanently attached. If you need a magnet to attach to something threaded, this is what you need.
