SMRN0648 Neodymium Ring Magnet | Stanford Magnets

SMRN0648 Neodymium Ring Magnet

Product ID: SMRN0648
Material: NdFeB
Shape: Ring
Dimension: 3/16” od x 1/16” id x 1/16” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 0.0067
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 0.7
Magnetization Direction: Through Thickness
Magnetic Face: 3/16″ od x 1/16″ id
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


SMRN0648 Neodymium Ring Magnet Introduction

The SMRN0648 ring neodymium magnet is made from high-performance N42 NdFeB, with Nickel coating. The dimension of this item is 3/16″ od × 1/16″ id × 1/16″ thick, magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.000415625 lbs. It can pull up to 0.7 lbs steel.

SMRN0648 Neodymium Ring Magnet Safety Tip

The smrn0648 neodymium ring magnet is so small that Children could swallow it easily. If several magnets are swallowed, they could get stuck in the intestine and cause perilous complications. Magnets are not toys. Make sure that children do not play with the smrn0648 neodymium ring magnet. The smrn0648 neodymium ring magnet could also be used as like push pins and fridge magnets. Keep track of all rare earth magnets in a home, not just those located in toys.
