SMRN0673 Neodymium RING Magnet

The SMRN0673 RING neodymium magnet is made from high performance N42 NdFeB, with Nickel coating. The dimension of this item is 1/2″ od × 1/8″ id × 1/2″ thick, magnetized Diametrical, with tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.0249375 lbs. It can pull up to 9.77 lbs steel. And the surface field is up to 6737 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMRN0673
Material: NdFeB
Shape: Ring
Dimension: 1/2” od x 1/8” id x 1/2” thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 0.4
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 9.77
Surface Field(Gauss): 6737
Magnetization direction: Diametrical
Max Operating Temp(C/F): 80/176
