SMRS0001 SmCo Ring Magnet - Stanford Magnets

SMRS0001 SmCo Ring Magnet

The SMRS0001 SmCo Ring Magnet is made from high performance 26M Sm2Co17, without other protective coating. The dimension of this item is 10mm dia ?? 5mm thickness, magnetized Through Thickness. It can pull up to 2.65 lbs steel. And the surface field is up to 3600 gauss.

INQUIRY Can't Find The Size

Follow Us On


Description

Product ID: SMRS0001
Material: Sm2Co17
Shape: Ring
Dimension: 10mm dia x 5mm thickness
Grade: 26M
Coating: Magnets Requiring no Protective Coating
Pull Force(Lbs): 2.65
Surface Field(Gauss): 3600
Magnetization direction: Through Thickness
Magnetic Face: 10mm dia
Max Operating Temp(C/F): 300/572
