SMRX436DCSPC-BLK Rubber Coated Magnets - Stanford Magnets

SMRX436DCSPC-BLK Rubber Coated Magnets

Dimensions: 1 1/4″ od x 0.221″ id x 0.402″ id x 3/8″ thick w/ hole to accept #10 screws
Tolerances: ±0.004″ x ±0.004″ x ±0.004″ x ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni Black Plastic
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 1.38 oz. (38.8 g)
Pull Force, Case 1: 20.49 lbs
Pull Force, Case 2: 39.87 lbs
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

The SMRX436DCSPC builds upon the strengths of our SMRX034DCSPC. Larger in both diameter and thickness means even more power and holding ability, all wrapped in a rugged, water-proof plastic coating. And since it is double countersunk, it’s also reversible. The aquarium enthusiast’s dream come true!
