SMCN0760 Neodymium Countersunk Magnet

Product ID: SMCN0760
Material: NdFeB
Shape: Countersunk
Dimension: 1” x 1” x 1/2” thick w/ hole to accept a #10 screw
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Weight(Oz.): 1.98
Grade: N42
Coating: Nickel Coated Magnets
Pull Force(Lbs): 48.45
Surface Field(Gauss): 3916
Magnetization Direction: Through Thickness
Magnetic Face: 1″ x 1″
Max Operating Temp(C/F): 80/176

INQUIRY Can't Find The Size

Follow Us On


The SMCN0760 countersunk neodymium magnet is made from high-performance N42 NdFeB, with Nickel coating. The dimension of this item is 1″ × 1″ × 1/2″ thick w/ hole to accept a #10 screw, magnetized through thickness, with the tolerance of ±0.004″ × ±0.004″ × ±0.004″. The weight of this super strong neodymium magnet is 0.12375 lbs. It can pull up to 48.45 lbs steel. And the surface field is up to 3916 gausses.
