SMON3150 Encased Ceramic Magnets (Al Case) | Stanford Magnets

SMON3150 Encased Ceramic Magnets (Al Case)

Product ID SMON3150
Material Ceramic (Ferrite)
Case Material Aluminum
Magnet Grade C8
Shape Disc
Mount Type Standard
Maximum Temperature 175℉
RoHS RoHS 3
INQUIRY Can't Find The Size

Follow Us On


Description

Encased Ceramic Magnets (Al Case) Introduction

Encased Ceramic Magnets (Al Case) feature a ceramic core encased in a protective housing, ensuring both durability and enhanced performance. With strong magnetic properties, they securely attract and hold objects in place. The encased design shields the ceramic core from external damage, making these magnets resistant to chipping, cracking, and corrosion.

Encased Ceramic Magnets (Al Case) Specification

Thick. OD Max. Pull, lbs. Sets of Poles
1/2″ 1/4″ 0.4 2
1/2″ 1/2″ 2.2 1
1″ 1/2″ 3 1
1″ 5/8″ 5 1
1″ 5/8″ 7 2
1″ 3/4″ 15 2
1″ 1″ 30 2
1 1/4″ 3/4″ 10 1
1 1/4″ 1 1/4″ 50 2



Encased Ceramic Magnets (Al Case) Applications

Encased Ceramic Magnets (Al Case) are ideal for various applications, from crafts and hobbies to industrial settings.

Encased Ceramic Magnets (Al Case)

Keywords: Encased Ceramic Magnets (Al Case)

Related products:

Encased Ceramic Magnets (Al Case) (Zinc-Plated Steel Case)

Encased Ceramic Magnet (Al Case)

Encased Ceramic Magnet (Steel Case)
